Diode Dynamics C2 1.0 SAE/DOT White with Amber Backlight Sport (7.7 watts) 2” LED Pod Combo Beam – Single

Diode Dynamics C2 1.0 SAE/DOT White Sport 2” LED Pod – Single

Get compact, high-intensity auxiliary lighting with the Diode Dynamics C2 1.0 Stage Series White Sport 2” LED Pod. Featuring custom-engineered TIR optics, a durable aluminum housing, and multiple functional beam patterns, the Diode Dynamics C2 1.0 LED Pod delivers precise illumination from a compact 2-inch package.

This configuration features the Sport power level and 6000K cool white output with an amber backlight and combo beam pattern.

This listing includes one (1) C2 1.0 LED Pod.

Key Features

• One Stage Series C2 1.0 2” LED Pod
• Sport power level
• 6000K cool white main output
• Custom-engineered TIR (Total Internal Reflection) optics
• Combo Beam Pattern
• Amber backlight
• Durable powder-coated aluminum construction
• Pin-fin heatsink design
• Integrated DT-type Deutsch-style connector
• Interchangeable lenses
• Tested for vibration, moisture intrusion, corrosion, and extreme temperatures
• Designed, torture-tested, and assembled in the USA
• Lifetime warranty

Compact Sport Performance

The C2 1.0 Sport combines high-intensity LED emitters with precision optics in a compact 2-inch LED pod.

Its small footprint makes it a versatile choice for auxiliary-lighting applications where mounting space is limited, while the Sport power level provides a strong balance of lighting performance and value.

Custom-Engineered TIR Optics

The C2 1.0 uses a custom-engineered Total Internal Reflection (TIR) optic rather than relying on a conventional reflector or simple lens.

The TIR optic collects light from the LED and precisely directs it into the intended beam pattern, helping reduce wasted light and unwanted glare while maximizing usable illumination.

The molded optic also serves as the main lens for greater optical efficiency.

Choose Your Beam Pattern

Configure your C2 1.0 Sport LED Pod with the beam pattern that best matches your application.

SAE Driving: Produces a focused 18x8-degree spread designed to supplement high beams while providing useful width for higher-speed driving.

SAE Fog: Uses Diode Dynamics’ FineLine optic to create an extremely wide 80-degree field of view for illuminating the area directly ahead of the vehicle.

Flood: Produces a uniform 60x60-degree spread ideal for backup lighting, trailers, worksites, and other low-speed applications.

Combo: Combines Driving and Flood optics to produce a 40x20-degree rectangular beam with both downrange and surrounding illumination.

Spot: Produces a highly focused 6-degree beam designed for long-distance illumination.

6000K Cool White Output

This C2 1.0 configuration features a 6000K cool white main output for crisp illumination that complements the appearance of many factory LED lighting systems.

Compatible replacement lenses are also available, allowing the optic or output color to be changed for different applications.

Amber or Red Backlight

Add a distinctive accent with your choice of an amber or red backlight.

Instead of illuminating only a small indicator LED, the C2 1.0 backlight illuminates the TIR optic itself for a clean, modern appearance when the main beam isn’t in use.

Always verify applicable vehicle-lighting regulations for your installation and intended backlight use.

SAE Driving & Fog Applications

When C2 1.0 LED Pods are installed as a pair and properly aimed according to applicable regulations, the white SAE Driving pattern meets SAE J581 requirements for a Driving/Auxiliary High Beam Light, while the SAE Fog pattern meets SAE J583 requirements for fog-lamp use.

Important: This listing includes only one C2 1.0 LED Pod. A second pod is required for the referenced paired SAE applications.

SAE compliance does not automatically apply to every beam pattern. Always check applicable state and local regulations for installation, aiming, and permitted on-road use.

Durable Stage Series Construction

The C2 1.0 features a durable powder-coated aluminum housing with a pin-fin heatsink design for effective thermal management.

Stage Series lighting is tested for long-term operation from -40°F to 185°F, along with vibration, moisture intrusion, and corrosion testing.

Simple Connections

The C2 1.0 features an integrated DT-type Deutsch-style connector and includes a 6-inch pigtail with bare leads.

This allows the pod to be integrated with an appropriate compatible wiring solution for your specific installation.

What’s Included

• One (1) Diode Dynamics Stage Series C2 1.0 2” LED Pod
• One (1) Deutsch-style wire pigtail
• One (1) mounting bracket with hardware

Power Level: Sport
Output Color: 6000K Cool White
Quantity: 1 LED pod
Warranty: Lifetime warranty
Designed, tested and assembled in: USA
